Basic Parameters
Built on Dongfeng EQ6682ZT3DY 4×4 off‑road bus chassis, SLT5120XYBV1 armoured troop‑carrying bus holds 23 passengers. It adopts six‑sided ballistic protection compliant with EN1063 standard, with adjustable B4‑B6 protection level. Equipped with panoramic bullet‑proof windshield and roof‑top high‑capacity air‑conditioning, it adapts perfectly to high‑temperature and complex field missions.
|
Body dimensions (L×W×H): |
6880×2400×3250 |
|---|---|
|
Drive form: |
4×4 |
|
Fuel: |
Diesel |
High‑output powertrain
Exceptional off‑road mobility
Heavy‑duty armored hull with mine‑blast resistance
AT automatic transmission
Rugged, commanding exterior design
| Engine: | 6.7L |
| Maximum power: | 210 kW 285hp |
| Peak torque: | 970 Nm |
| Gearbox: | 6-speed manual |
| Drive form: | 4×4 |
| Fuel type: | Diesel |
| Body dimensions (L×W×H): | 6880×2400×3250 |
| Wheelbase: | 3800 mm |
| Bulletproof level: | B4 – B6 |
